رمز المنتج : VF--QCC-Q217-CU
Valve Design
Based on API 6D, API 600, ASME B16.34, ISO 14313, ISO 10423, ISO 17292
Temperature range
-320 to 1112°F (-196 to 600°C)
Size
NPS 2-24 (DN 2-600)
Pressure level
ASME 150-ASME 2500
Structural length
According to the API 6D standard
Connection method
RF and RTJ comply with B16.5 and B16.47
BW, weld and butt in accordance with B16.25
Materials:
Carbon steel, stainless steel, duplex stainless steel, super duplex stainless steel, nickel-based alloy
Valve body design
Forged or cast single-piece type
Valve seat design
Single-seat design
The single fixed valve seat in the valve provides bidirectional sealing, avoiding the problem of residual pressure between seals.
Valve stem seal
There is no friction between the sealing surfaces
With its unique structure, the valve stem and valve seat have no friction during the opening and closing of the valve, which can extend the service life of the valve and make the sealing more reliable.
Operation mode
Handwheels, gearboxes or actuators with position indicators and locking devices
Testing and certification
Comply with API 6D& ISO 5208 and API 598 inspection and testing
Comply with the fire protection standards and fire protection tests of API 607
SIL 3 certification in compliance with IEC61508
Emissions that comply with ISO15848
PED 2014/68 / UE
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| المنتج | رمز المنتج | النقاء | الحجم | تواصل معنا |
The track ball valve, with its unique design, especially features a frictionless opening process and zero leakage during closing. The performance is particularly suitable for various extremely demanding working conditions with special requirements. It features an all-metal structure design, fireproof design, and can adapt to a low-temperature range of -196°C(-320°F) and a high-temperature range of up to 600°C(1112°F) or operating temperature. It can also meet the requirements of impurity media (including sand and short fibers).
The track ball valve, with its unique design, especially features a frictionless opening process and zero leakage during closing. The performance is particularly suitable for various extremely demanding working conditions with special requirements. It features an all-metal structure design, fireproof design, and can adapt to a low-temperature range of -196°C(-320°F) and a high-temperature range of up to 600°C(1112°F) or operating temperature. It can also meet the requirements of impurity media (including sand and short fibers).
