رمز المنتج : VF--DCCC-DC27-CU
Technical parameters:
Nominal diameter (mm) : 15-200
Applicable media: water, liquid, foam fire extinguishing agent, CO2 gas
Connection method: ≤DN50 pipe thread/or standard flange; ≥DN65 standard flange
Medium pressure: ZSPC:0.1-1.6Mpa,ZSPG:0.1-2.5Mpa,ZCPH:0.4-4.0Mpa (Direct-acting type can be customized)
Medium temperature: ≤80℃ \ nAmbient temperature: -20℃ to +40℃
Power supply voltage: Various voltages including AC and DC
Structural form: Recoil piston type
Material: ≤DN50: Copper body, stainless steel core, all stainless steel ≥DN65: Cast iron body/cast steel body, stainless steel core, all stainless steel
Protective function options: Explosion-proof type (grade ExdIICT4), waterproof type (grade IP67)
Other optional functions: Manual device, valve opening/closing contact feedback, check function;
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| المنتج | رمز المنتج | النقاء | الحجم | تواصل معنا |
Working principle When the electromagnetic coil of the solenoid valve is energized, the moving iron core is attracted, driving the valve stem to move upward. At the same time, the spring is compressed, causing the valve stem to separate from the middle hole (pilot hole) of the valve core. The fluid in the upper chamber of the valve core is instantly depressed from the middle hole. After the pressure is depressed, the valve core rapidly rises upward under the action of the pressure difference between the upper and lower chambers, and the solenoid valve opens. When the coil of the solenoid valve is de-energized, the valve stem closes the middle hole of the valve core under the action of the spring force and pushes the valve core downward to seal the fluid outlet, thus closing the solenoid valve.
Main features
The valve body adopts a spherical low-flow resistance structure, featuring small pressure loss and large flow capacity.
The valve core adopts a stainless steel piston structure, featuring anti-rust, flexible start-up, water hammer resistance and long service life.
The coil adopts a moisture-proof sealed metal casing and can be used in outdoor humid environments (specially designed).
The coil adopts a composite high-quality enameled wire with excellent insulation performance. It is equipped with a military-grade high-quality bridge rectifier and overcurrent protection components, featuring powerful performance and reliable operation.
Product application: The fire-fighting dedicated solenoid valve is a dedicated matching valve for various automatic sprinkler fire extinguishing systems. It can be used to control rain systems, water curtain systems, water spray systems and pre-action systems. When a fire detects a fire signal and transmits it to the control box, confirming the occurrence of a fire, it will send an opening signal to the solenoid valve, thereby activating systems such as rain showers and water curtains. It can also be installed at the end of the rainwater system pipeline network to automatically detect the reliability of the system, and can be used in the automatic control systems of other oil, water and other systems.
